| WLCM | 300 | 500 | 1000 | |
|---|---|---|---|---|
|
Operating Environment |
Voltage |
Single-phase 220V±10%, 50/60Hz AC
|
||
|
Operating Ambient Temperature
|
5℃～40℃
|
|||
|
Working AmbientHumidity
|
≤80% |
|||
|
Laser Optics Argument |
Average Output Power (W)
|
>1000
|
>500
|
>300
|
|
Output Cable Length (m)
|
5 |
10 |
10 |
|
|
Max. Pulse Energy (mJ)
|
12.5 |
15 |
15/50 |
|
|
Frequency Adjustable Range |
1-4000
|
10-1000
|
1-4000
|
|
|
Pulse Width (ns) |
2-500 |
30-500
|
30-500
|
|
|
Cooling Model
|
Water cooling |
|||
|
Controlling Power Range (%) |
0～100 |
|||
|
Supply Voltage (V)
|
48V >30A |
220V
|
220V
|
|
|
Controlling Power Range
|
0～100
|
|||
|
Central Wavelength (nm)
|
1064
|
|||
|
Cleaning System Parameter
|
Scanning Range (mm)
|
1~350mm(limited by field mirror)
|
||
|
Scanning Speed |
0~30000mm/s
|
|||
|
Field Mirror Focal Length
|
100~530(limited by field mirror)
|
|||
|
Cleaning Mode
|
8 kinds |
|||
|
System cable length (m)
|
5 |
10 |
10 |
|
|
Laser |
JPT |
|||
|
Weight |
178KG |
|||
